Advanced Subgraph Features

Panoramica

Add and implement advanced Subgraph features to enhanced your Subgraph’s built.

Starting from specVersion 0.0.4, Subgraph features must be explicitly declared in the features section at the top level of the manifest file, using their camelCase name, as listed in the table below:

For instance, if a Subgraph uses the Full-Text Search and the Non-fatal Errors features, the features field in the manifest should be:

1specVersion: 1.3.02description: Gravatar for Ethereum3features:4  - fullTextSearch5  - nonFatalErrors6dataSources: ...

Timeseries and Aggregations

Prerequisites:

• Subgraph specVersion must be ≥1.1.0.

Timeseries and aggregations enable your Subgraph to track statistics like daily average price, hourly total transfers, and more.

This feature introduces two new types of Subgraph entity. Timeseries entities record data points with timestamps. Aggregation entities perform pre-declared calculations on the timeseries data points on an hourly or daily basis, then store the results for easy access via GraphQL.

Example Schema

1type Data @entity(timeseries: true) {2  id: Int8!3  timestamp: Timestamp!4  price: BigDecimal!5}67type Stats @aggregation(intervals: ["hour", "day"], source: "Data") {8  id: Int8!9  timestamp: Timestamp!10  sum: BigDecimal! @aggregate(fn: "sum", arg: "price")11}

How to Define Timeseries and Aggregations

Timeseries entities are defined with @entity(timeseries: true) in the GraphQL schema. Every timeseries entity must:

• have a unique ID of the int8 type
• have a timestamp of the Timestamp type
• include data that will be used for calculation by aggregation entities.

These Timeseries entities can be saved in regular trigger handlers, and act as the “raw data” for the aggregation entities.

Aggregation entities are defined with @aggregation in the GraphQL schema. Every aggregation entity defines the source from which it will gather data (which must be a timeseries entity), sets the intervals (e.g., hour, day), and specifies the aggregation function it will use (e.g., sum, count, min, max, first, last).

Aggregation entities are automatically calculated on the basis of the specified source at the end of the required interval.

Available Aggregation Intervals

• hour: sets the timeseries period every hour, on the hour.
• day: sets the timeseries period every day, starting and ending at 00:00.

Available Aggregation Functions

• sum: Total of all values.
• count: Number of values.
• min: Minimum value.
• max: Maximum value.
• first: First value in the period.
• last: Last value in the period.

Example Aggregations Query

1{2  stats(interval: "hour", where: { timestamp_gt: 1704085200 }) {3    id4    timestamp5    sum6  }7}

Read more⁠ about Timeseries and Aggregations.

Errori non fatali

Indexing errors on already synced Subgraphs will, by default, cause the Subgraph to fail and stop syncing. Subgraphs can alternatively be configured to continue syncing in the presence of errors, by ignoring the changes made by the handler which provoked the error. This gives Subgraph authors time to correct their Subgraphs while queries continue to be served against the latest block, though the results might be inconsistent due to the bug that caused the error. Note that some errors are still always fatal. To be non-fatal, the error must be known to be deterministic.

Enabling non-fatal errors requires setting the following feature flag on the Subgraph manifest:

1specVersion: 1.3.02description: Gravatar for Ethereum3features:4    - nonFatalErrors5    ...

The query must also opt-in to querying data with potential inconsistencies through the subgraphError argument. It is also recommended to query _meta to check if the Subgraph has skipped over errors, as in the example:

1foos(first: 100, subgraphError: allow) {2  id3}45_meta {6  hasIndexingErrors7}

If the Subgraph encounters an error, that query will return both the data and a graphql error with the message "indexing_error", as in this example response:

1"data": {2    "foos": [3        {4          "id": "0xdead"5        }6    ],7    "_meta": {8        "hasIndexingErrors": true9    }10},11"errors": [12    {13        "message": "indexing_error"14    }15]

IPFS/Arweave File Data Sources

File data sources are a new Subgraph functionality for accessing off-chain data during indexing in a robust, extendable way. File data sources support fetching files from IPFS and from Arweave.

Panoramica

Rather than fetching files “in line” during handler execution, this introduces templates which can be spawned as new data sources for a given file identifier. These new data sources fetch the files, retrying if they are unsuccessful, running a dedicated handler when the file is found.

This is similar to the existing data source templates, which are used to dynamically create new chain-based data sources.

Guida all’aggiornamento

Update graph-ts and graph-cli

File data sources requires graph-ts >=0.29.0 and graph-cli >=0.33.1

Aggiungere un nuovo tipo di entità che verrà aggiornato quando verranno trovati dei file

I data sources file non possono accedere o aggiornare le entità basate sulla chain, ma devono aggiornare le entità specifiche del file.

Ciò può significare dividere i campi delle entità esistenti in entità separate, collegate tra loro.

Entità combinata originale:

1type Token @entity {2  id: ID!3  tokenID: BigInt!4  tokenURI: String!5  externalURL: String!6  ipfsURI: String!7  image: String!8  name: String!9  description: String!10  type: String!11  updatedAtTimestamp: BigInt12  owner: User!13}

Entità nuova, divisa:

1type Token @entity {2  id: ID!3  tokenID: BigInt!4  tokenURI: String!5  ipfsURI: TokenMetadata6  updatedAtTimestamp: BigInt7  owner: String!8}910type TokenMetadata @entity {11  id: ID!12  image: String!13  externalURL: String!14  name: String!15  description: String!16}

Se la relazione è 1:1 tra l’entità genitore e l’entità data source file risultante, il modello più semplice è quello di collegare l’entità genitore a un’entità file risultante utilizzando il CID IPFS come lookup. Contattateci su Discord se avete difficoltà a modellare le vostre nuove entità basate su file!

Add a new templated data source with kind: file/ipfs or kind: file/arweave

È l’origine dati che verrà generata quando viene identificato un file di interesse.

1templates:2  - name: TokenMetadata3    kind: file/ipfs4    mapping:5      apiVersion: 0.0.96      language: wasm/assemblyscript7      file: ./src/mapping.ts8      handler: handleMetadata9      entities:10        - TokenMetadata11      abis:12        - name: Token13          file: ./abis/Token.json

The file data source must specifically mention all the entity types which it will interact with under entities. See limitations for more details.

Creare un nuovo gestore per elaborare i file

This handler should accept one Bytes parameter, which will be the contents of the file, when it is found, which can then be processed. This will often be a JSON file, which can be processed with graph-ts helpers (documentation).

The CID of the file as a readable string can be accessed via the dataSource as follows:

1const cid = dataSource.stringParam()

Esempio di gestore:

1import { json, Bytes, dataSource } from '@graphprotocol/graph-ts'2import { TokenMetadata } from '../generated/schema'34export function handleMetadata(content: Bytes): void {5  let tokenMetadata = new TokenMetadata(dataSource.stringParam())6  const value = json.fromBytes(content).toObject()7  if (value) {8    const image = value.get('image')9    const name = value.get('name')10    const description = value.get('description')11    const externalURL = value.get('external_url')1213    if (name && image && description && externalURL) {14      tokenMetadata.name = name.toString()15      tokenMetadata.image = image.toString()16      tokenMetadata.externalURL = externalURL.toString()17      tokenMetadata.description = description.toString()18    }1920    tokenMetadata.save()21  }22}

Creare i data source file quando necessario

È ora possibile creare i data sources file durante l’esecuzione di gestori a chain:

• Import the template from the auto-generated templates
• call TemplateName.create(cid: string) from within a mapping, where the cid is a valid content identifier for IPFS or Arweave

For IPFS, Graph Node supports v0 and v1 content identifiers⁠, and content identifiers with directories (e.g. bafyreighykzv2we26wfrbzkcdw37sbrby4upq7ae3aqobbq7i4er3tnxci/metadata.json).

For Arweave, as of version 0.33.0 Graph Node can fetch files stored on Arweave based on their transaction ID⁠ from an Arweave gateway (example file⁠). Arweave supports transactions uploaded via Irys (previously Bundlr), and Graph Node can also fetch files based on Irys manifests⁠.

Example:

1import { TokenMetadata as TokenMetadataTemplate } from '../generated/templates'23const ipfshash = 'QmaXzZhcYnsisuue5WRdQDH6FDvqkLQX1NckLqBYeYYEfm'4//This example code is for a Crypto coven Subgraph. The above ipfs hash is a directory with token metadata for all crypto coven NFTs.56export function handleTransfer(event: TransferEvent): void {7  let token = Token.load(event.params.tokenId.toString())8  if (!token) {9    token = new Token(event.params.tokenId.toString())10    token.tokenID = event.params.tokenId1112    token.tokenURI = '/' + event.params.tokenId.toString() + '.json'13    const tokenIpfsHash = ipfshash + token.tokenURI14    //This creates a path to the metadata for a single Crypto coven NFT. It concats the directory with "/" + filename + ".json"1516    token.ipfsURI = tokenIpfsHash1718    TokenMetadataTemplate.create(tokenIpfsHash)19  }2021  token.updatedAtTimestamp = event.block.timestamp22  token.owner = event.params.to.toHexString()23  token.save()24}

Questo creerà una nuova data source file, che interrogherà l’endpoint IPFS o Arweave configurato del Graph Node, ritentando se non viene trovato. Quando il file viene trovato, viene eseguito il gestore del data source file.

This example is using the CID as the lookup between the parent Token entity and the resulting TokenMetadata entity.

Congratulazioni, state usando i data source file!

Deploying your Subgraphs

You can now build and deploy your Subgraph to any Graph Node >=v0.30.0-rc.0.

Limitazioni

File data source handlers and entities are isolated from other Subgraph entities, ensuring that they are deterministic when executed, and ensuring no contamination of chain-based data sources. To be specific:

• Le entità create di Data Source file sono immutabili e non possono essere aggiornate
• I gestori di Data Source file non possono accedere alle entità di altre data source file
• Le entità associate al Data Source file non sono accessibili ai gestori alla chain

Inoltre, non è possibile creare data source da una data source file, sia essa una data source onchain o un’altra data source file. Questa restrizione potrebbe essere eliminata in futuro.

Migliori pratiche

Se si collegano i metadati NFT ai token corrispondenti, utilizzare l’hash IPFS dei metadati per fare riferimento a un’entità Metadata dall’entità Token. Salvare l’entità Metadata usando l’hash IPFS come ID.

You can use DataSource context when creating File Data Sources to pass extra information which will be available to the File Data Source handler.

If you have entities which are refreshed multiple times, create unique file-based entities using the IPFS hash & the entity ID, and reference them using a derived field in the chain-based entity.

Problemi conosciuti

File data sources currently require ABIs, even though ABIs are not used (issue⁠). Workaround is to add any ABI.

Handlers for File Data Sources cannot be in files which import eth_call contract bindings, failing with “unknown import: ethereum::ethereum.call has not been defined” (issue⁠). Workaround is to create file data source handlers in a dedicated file.

Esempi

Crypto Coven Subgraph migration⁠

Riferimenti

GIP File Data Sources⁠

Indexed Argument Filters / Topic Filters

Topic filters, also known as indexed argument filters, are a powerful feature in Subgraphs that allow users to precisely filter blockchain events based on the values of their indexed arguments.

• These filters help isolate specific events of interest from the vast stream of events on the blockchain, allowing Subgraphs to operate more efficiently by focusing only on relevant data.

• This is useful for creating personal Subgraphs that track specific addresses and their interactions with various smart contracts on the blockchain.

How Topic Filters Work

When a smart contract emits an event, any arguments that are marked as indexed can be used as filters in a Subgraph’s manifest. This allows the Subgraph to listen selectively for events that match these indexed arguments.

• The event’s first indexed argument corresponds to topic1, the second to topic2, and so on, up to topic3, since the Ethereum Virtual Machine (EVM) allows up to three indexed arguments per event.

1// SPDX-License-Identifier: MIT2pragma solidity ^0.8.0;34contract Token {5    // Event declaration with indexed parameters for addresses6    event Transfer(address indexed from, address indexed to, uint256 value);78    // Function to simulate transferring tokens9    function transfer(address to, uint256 value) public {10        // Emitting the Transfer event with from, to, and value11        emit Transfer(msg.sender, to, value);12    }13}

In this example:

• The Transfer event is used to log transactions of tokens between addresses.
• The from and to parameters are indexed, allowing event listeners to filter and monitor transfers involving specific addresses.
• The transfer function is a simple representation of a token transfer action, emitting the Transfer event whenever it is called.

Configuration in Subgraphs

Topic filters are defined directly within the event handler configuration in the Subgraph manifest. Here is how they are configured:

1eventHandlers:2  - event: SomeEvent(indexed uint256, indexed address, indexed uint256)3    handler: handleSomeEvent4    topic1: ['0xValue1', '0xValue2']5    topic2: ['0xAddress1', '0xAddress2']6    topic3: ['0xValue3']

In this setup:

• topic1 corresponds to the first indexed argument of the event, topic2 to the second, and topic3 to the third.
• Each topic can have one or more values, and an event is only processed if it matches one of the values in each specified topic.

Filter Logic

• Within a Single Topic: The logic functions as an OR condition. The event will be processed if it matches any one of the listed values in a given topic.
• Between Different Topics: The logic functions as an AND condition. An event must satisfy all specified conditions across different topics to trigger the associated handler.

Example 1: Tracking Direct Transfers from Address A to Address B

1eventHandlers:2  - event: Transfer(indexed address,indexed address,uint256)3    handler: handleDirectedTransfer4    topic1: ['0xAddressA'] # Sender Address5    topic2: ['0xAddressB'] # Receiver Address

In this configuration:

• topic1 is configured to filter Transfer events where 0xAddressA is the sender.
• topic2 is configured to filter Transfer events where 0xAddressB is the receiver.
• The Subgraph will only index transactions that occur directly from 0xAddressA to 0xAddressB.

Example 2: Tracking Transactions in Either Direction Between Two or More Addresses

1eventHandlers:2  - event: Transfer(indexed address,indexed address,uint256)3    handler: handleTransferToOrFrom4    topic1: ['0xAddressA', '0xAddressB', '0xAddressC'] # Sender Address5    topic2: ['0xAddressB', '0xAddressC'] # Receiver Address

In this configuration:

• topic1 is configured to filter Transfer events where 0xAddressA, 0xAddressB, 0xAddressC is the sender.
• topic2 is configured to filter Transfer events where 0xAddressB and 0xAddressC is the receiver.
• The Subgraph will index transactions that occur in either direction between multiple addresses allowing for comprehensive monitoring of interactions involving all addresses.

Declared eth_call

Declarative eth_calls are a valuable Subgraph feature that allows eth_calls to be executed ahead of time, enabling graph-node to execute them in parallel.

This feature does the following:

• Significantly improves the performance of fetching data from the Ethereum blockchain by reducing the total time for multiple calls and optimizing the Subgraph’s overall efficiency.
• Allows faster data fetching, resulting in quicker query responses and a better user experience.
• Reduces wait times for applications that need to aggregate data from multiple Ethereum calls, making the data retrieval process more efficient.

Key Concepts

• Declarative eth_calls: Ethereum calls that are defined to be executed in parallel rather than sequentially.
• Parallel Execution: Instead of waiting for one call to finish before starting the next, multiple calls can be initiated simultaneously.
• Time Efficiency: The total time taken for all the calls changes from the sum of the individual call times (sequential) to the time taken by the longest call (parallel).

Scenario without Declarative eth_calls

Imagine you have a Subgraph that needs to make three Ethereum calls to fetch data about a user’s transactions, balance, and token holdings.

Traditionally, these calls might be made sequentially:

1. Call 1 (Transactions): Takes 3 seconds
2. Call 2 (Balance): Takes 2 seconds
3. Call 3 (Token Holdings): Takes 4 seconds

Total time taken = 3 + 2 + 4 = 9 seconds

Scenario with Declarative eth_calls

With this feature, you can declare these calls to be executed in parallel:

1. Call 1 (Transactions): Takes 3 seconds
2. Call 2 (Balance): Takes 2 seconds
3. Call 3 (Token Holdings): Takes 4 seconds

Since these calls are executed in parallel, the total time taken is equal to the time taken by the longest call.

Total time taken = max (3, 2, 4) = 4 seconds

How it Works

1. Declarative Definition: In the Subgraph manifest, you declare the Ethereum calls in a way that indicates they can be executed in parallel.
2. Parallel Execution Engine: The Graph Node’s execution engine recognizes these declarations and runs the calls simultaneously.
3. Result Aggregation: Once all calls are complete, the results are aggregated and used by the Subgraph for further processing.

Example Configuration in Subgraph Manifest

Declared eth_calls can access the event.address of the underlying event as well as all the event.params.

subgraph.yaml using event.address:

1eventHandlers:2event: Swap(indexed address,indexed address,int256,int256,uint160,uint128,int24)3handler: handleSwap4calls:5  global0X128: Pool[event.address].feeGrowthGlobal0X128()6  global1X128: Pool[event.address].feeGrowthGlobal1X128()

Details for the example above:

• global0X128 is the declared eth_call.
• The text (global0X128) is the label for this eth_call which is used when logging errors.
• The text (Pool[event.address].feeGrowthGlobal0X128()) is the actual eth_call that will be executed, which is in the form of Contract[address].function(arguments)
• The address and arguments can be replaced with variables that will be available when the handler is executed.

subgraph.yaml using event.params

1calls:2  - ERC20DecimalsToken0: ERC20[event.params.token0].decimals()

Grafting su subgraph esistenti

When a Subgraph is first deployed, it starts indexing events at the genesis block of the corresponding chain (or at the startBlock defined with each data source) In some circumstances; it is beneficial to reuse the data from an existing Subgraph and start indexing at a much later block. This mode of indexing is called Grafting. Grafting is, for example, useful during development to get past simple errors in the mappings quickly or to temporarily get an existing Subgraph working again after it has failed.

A Subgraph is grafted onto a base Subgraph when the Subgraph manifest in subgraph.yaml contains a graft block at the top-level:

1description: ...2graft:3  base: Qm... # Subgraph ID of base Subgraph4  block: 7345624 # Block number

When a Subgraph whose manifest contains a graft block is deployed, Graph Node will copy the data of the base Subgraph up to and including the given block and then continue indexing the new Subgraph from that block on. The base Subgraph must exist on the target Graph Node instance and must have indexed up to at least the given block. Because of this restriction, grafting should only be used during development or during an emergency to speed up producing an equivalent non-grafted Subgraph.

Because grafting copies rather than indexes base data, it is much quicker to get the Subgraph to the desired block than indexing from scratch, though the initial data copy can still take several hours for very large Subgraphs. While the grafted Subgraph is being initialized, the Graph Node will log information about the entity types that have already been copied.

The grafted Subgraph can use a GraphQL schema that is not identical to the one of the base Subgraph, but merely compatible with it. It has to be a valid Subgraph schema in its own right, but may deviate from the base Subgraph’s schema in the following ways:

• It adds or removes entity types
• It removes attributes from entity types
• It adds nullable attributes to entity types
• It turns non-nullable attributes into nullable attributes
• It adds values to enums
• It adds or removes interfaces
• It changes for which entity types an interface is implemented
